lntellian i6/i6P
Specification
lntellian i6
|
|
Physical
|
|
|
|
Dimensions(diameter
x height)尺寸（直徑×高度）
|
70 x 72 cm
(27.5"x
28.3")
70 × 72厘米 |
|
Weight重量
|
20 kg ( 44
lbs)
22KG |
|
Antenna Dish天線碟
|
60 cm
(23.6")
60厘米 |
|
|
|
|
|
|
Environmental
環境
|
|
|
|
Operating Temp.溫度范圍 |
-15˚C to +55˚C (+5˚F to
+131˚F) -25 ˚ C至55
˚c
|
|
Storage Temp.貯藏溫
Range范圍 |
-25˚C to +70˚C (-13˚F to
+158˚F) -40˚ C至80 ˚
ç
|
|
Approved批準
|
CE and FCC CE認證和FCC
|
|
|
|
|
|
|
Performance性能
|
|
|
|
Frequency頻率
|
Ku-Band(10.7 ~ 12.75 GHz)
Ku波段（ 10.7 〜 12.75千兆赫）
|
|
Minimum EIRPEIRP
|
47 dBW 46 dBW
|
|
Azimuth Range方位角范圍
|
680˚ 680 ˚
|
|
Elevation Range海拔范圍
|
+5˚ to +90˚ 5 ˚到90 ˚
|
|
Ship's Motion船舶的運動
|
Roll ±25˚ , Pitch ±15˚輥±
25 ˚ ，間距± 15 ˚
Roll ±25˚ , Pitch ±15˚ |
|
Roll & Pitch Response Rate軋輥及回應率
|
45˚ / second 45 ˚ /秒
|
|
Turn Rate轉彎速率
|
45˚ / second 45 ˚ /秒
|
|
Repeatability重復性
|
0.1˚ 0.1 ˚
|
|
LNBLNB
|
Dual Output / Quad Output雙輸出/四輸出
|
|
|
|
|
|
|
ACU (Antenna Control
Unit)天線控制單元 |
|
|
|
Dimensions |
178 x 217 x 54 mm (7" x 8.5"
x 2.1")
|
|
Weight重量
|
1.2 kg (2.6 lbs)
1.2公斤 |
|
Display顯示
|
2 Line 20 Character VFD
Module
顯示模塊
|
|
Control Key控制鍵
|
5 Integrated Push Buttons
5集成按鈕
|
|
Serial Interface串行接口
|
|
|
Power電力
|
Input : DC 9.0~30.0V (Typ.
30W, Max 50W)輸入：直流9.0
〜 30.0V （30W ）
|
|
GPS Interface系統接口
|
Built-In (NMEA 0183 GPS)內置的數據 |
|
Remote Control Interface遠程控制接口
|
Available可用 |
|
|
|
* The above picture
is the lntellian
i6P, mounted on the
boat.
*以上圖片是lntellian i6，安裝在船上。
|
|
|
